Circuit Protection
Filter
Showing all 3 results
- Automotive-grade protection: Survives ±30 kV IEC 61000-4-2 ESD and 5 A (8/20 µs) surge for CAN/LIN and 12/24 V rails.
- Signal-friendly capacitance: ~24 pF typ. line-to-line to preserve bus edges and bandwidth.
- Flexible SOT-23 pinout: Two-line unidirectional or single-line bidirectional (pins 1–2) by leaving pin 3 floating.
- Bidirectional Clamping: Guards against both positive and negative transients.
- Low Clamping Ratio: Vc/Vbr = 1.63 for superior energy absorption.
- Glass-Passivated Junction: Enhanced reliability vs epoxy-coated competitors.
The STMicroelectronics USBLC6-2SC6 is an advanced TVS diode designed to protect sensitive high-speed interfaces while maintaining low capacitance, fast response, and superior ESD immunity. Whether in consumer electronics, industrial systems, or automotive applications, it ensures uninterrupted data transmission while safeguarding against transient voltage threats.
With compact packaging, optimized power efficiency, and full compliance with USB 2.0/Ethernet standards, it is the ideal choice for engineers seeking robust yet sleek ESD protection solutions.
