2920L050DR Littelfuse 2920L050DR PTC Resettable Fuses Surface Mount 1.4O 500mA 1A 60V 85°C -40°C
Littelfuse 2920L050DR PTC Resettable Fuse 0.5A(hold) 1A(trip) 60VDC 10A 1.5W 4s 0.35Ohm SMD Solder Pad 2920 T/R
Littelfuse 2920L050DR PTC Resettable Fuses Overview
PTC Resettable Fuse 0.5A(hold) 1A(trip) 60VDC 10A 1.5W 4s 0.35Ohm SMD Solder Pad 2920 T/R
Key Features of Littelfuse 2920L050DR PTC Resettable Fuses
- Trip Current: 1A
- Resistance: 1.4O
- Mount: Surface Mount
- Min Operating Temperature: -40°C
- Voltage Rating: 60V
- Hold Current: 500mA
- Max Operating Temperature: 85°C
Littelfuse 2920L050DR Specifications
General
| Ambient Temperature Range High | 85°C |
| Approvals | TUV, cULus |
| Case Code (Imperial) | 2920 |
| Case Code (Metric) | 7351 |
| Case/Package | 2920 |
| Current Rating | 10A |
| Height | 1.25mm |
| Hold Current | 500mA |
| Lead Free | Lead Free |
| Length | 7.98mm |
| Lifecycle Status | Production |
| Max Current Rating | 10A |
| Max Operating Temperature | 85°C |
| Max Voltage Rating (DC) | 60V |
| Min Operating Temperature | -40°C |
| Mount | Surface Mount |
| Number of Pins | 2 |
| Operating Supply Voltage | 60V |
| Power Dissipation | 1.5W |
| REACH SVHC | No |
| Resistance | 1.4O |
| RoHS | Compliant |
| Terminal Material | Copper |
| Termination | SMD/SMT |
| Time to Trip | 4s |
| Trip Current | 1A |
| Voltage Rating | 60V |
| Voltage Rating (DC) | 60V |
| Width | 5.44mm |
Specification: Littelfuse 2920L050DR PTC Resettable Fuses Surface Mount 1.4O 500mA 1A 60V 85°C -40°C
|
