CDLL4686 Microchip CDLL4686 Zener Diodes 3.9V 500mW 5µA 5%

Microchip CDLL4686 Zener Diodes Overview

The Microchip Zener Diode Single 3.9V 5% 500mW 2-Pin DO-213AA is a reliable and efficient electronic component designed for voltage regulation and protection in various applications. With a Zener voltage of 3.9V and a power dissipation capability of 500mW, this surface mount diode ensures optimal performance in demanding environments. Its compact 2-pin DO-213AA package and robust specifications make it an ideal choice for both consumer and industrial electronics, providing stability and precision in voltage management.

Key Features of Microchip CDLL4686 Zener Diodes

• Engineered to power Dissipation: 500mW, supporting dependable performance in real-world designs.
• Engineered to roHS Compliant, supporting dependable performance in real-world designs.
• Optimized to max Reverse Leakage Current: 5µA, improving robustness in practical applications.
• Engineered to operating Temperature Range: -65°C to 175°C, supporting dependable performance in real-world designs.
• Built to surface Mount Configuration, making integration easier across a wide range of systems.
• Designed to zener Voltage: 3.9V, helping ensure consistent and reliable operation.
• Designed to lifecycle Status: Production, helping ensure consistent and reliable operation.
