AGLN010V2-UCG36I Microchip AGLN010V2-UCG36I Field Programmable Gate Arrays (FPGAs) 23 I/Os 260 Logic Elements/Cells 250MHz

Microchip AGLN010V2-UCG36I Field Programmable Gate Arrays (FPGAs) Overview

The Microchip FPGA IGLOO nano Family 10K Gates is a cutting-edge Field Programmable Gate Array (FPGA) designed for applications requiring high performance and flexibility. With its advanced 130nm CMOS technology, this 36-pin UCSP package delivers exceptional processing capabilities, featuring 10,000 gates and 260 logic elements. Operating at a supply voltage of 1.5V and a maximum frequency of 250MHz, this FPGA is ideal for a variety of applications, from consumer electronics to industrial automation, all while ensuring low power consumption and robust performance across a wide temperature range.

Key Features of Microchip AGLN010V2-UCG36I Field Programmable Gate Arrays (FPGAs)

• Engineered to 10,000 Gates with 260 Logic Elements, supporting dependable performance in real-world designs.
• Designed to operating Supply Voltage: 1.5V, helping ensure consistent and reliable operation.
• Engineered to max Frequency: 250MHz, supporting dependable performance in real-world designs.
• Engineered to 36-Pin Surface Mount Package (WFBGA), supporting dependable performance in real-world designs.
• Built to lead Free and RoHS Compliant, making integration easier across a wide range of systems.
• Optimized to wide Operating Temperature Range (-40°C to 85°C), improving robustness in practical applications.
• Optimized to low Power Consumption: 3µA Operating Current, improving robustness in practical applications.
