A40MX04-PL84I Microchip A40MX04-PL84I Field Programmable Gate Arrays (FPGAs) 69 I/Os 547 Logic Elements/Cells 139MHz

Microchip A40MX04-PL84I Field Programmable Gate Arrays (FPGAs) Overview

FPGA 40MX Family 6K Gates 547 Cells 83MHz/139MHz 0.45um Technology 3.3V/5V 84-Pin PLCC Box

Key Features of Microchip A40MX04-PL84I Field Programmable Gate Arrays (FPGAs)

• Built to number of Logic Elements/Cells: 547, making integration easier across a wide range of systems.
• Designed to max Frequency: 139MHz, helping ensure consistent and reliable operation.
• Built to number of I/Os: 69, making integration easier across a wide range of systems.
