W2E200-HH82-18 ebm-papst W2E200-HH82-18 AC Axial Fan | 115V 500 CFM IP44 Ball Bearing Industrial Fan
The ebm-papst W2E200-HH82-18 is a 115V AC axial fan delivering 500 CFM airflow, featuring ball bearings, die-cast aluminum housing, and IP44 protection. Ideal for HVAC, machinery cooling, and ventilation systems, with 56 dB(A) noise level and thermal overload protection.
Key Features
🔄 High Efficiency: 500 CFM (14.16 m³/min) airflow at 2450 RPM for reliable cooling.
🛡 Durable Design: Ball bearings & die-cast aluminum frame ensure long service life.
🔌 Easy Installation: 3-wire leads for flexible wiring connections.
In Stock
Request a Quoteebm-papst W2E200-HH82-18 AC Axial Fan – Reliable Industrial Airflow Solution
The W2E200-HH82-18 is a 115V AC axial fan from ebm-papst’s W2E200 series, engineered for industrial ventilation, HVAC systems, and equipment cooling. Its shaded-pole motor, ball bearings, and sealed housing make it a dependable choice for high-duty applications.
Technical Specifications (Product Attributes Table)
| Parameter | Specification |
|---|---|
| Manufacturer | ebm-papst Inc. |
| Series | W2E200 (Industrial AC Axial Fans) |
| Model | W2E200-HH82-18 |
| Voltage Rating | 115V AC (±10%) |
| Airflow | 500 CFM (14.16 m³/min) |
| Speed | 2450 RPM (Fixed) |
| Noise Level | 56 dB(A) (Low Noise) |
| Power Consumption | 60W |
| Current (Amps) | 0.53A |
| Bearing Type | Ball Bearing (50,000+ Hours Lifespan) |
| Frame Material | Die-Cast Aluminum (Lightweight & Robust) |
| Blade Material | Steel (Welded Impeller) |
| Operating Temperature | -25°C to +50°C (Wide Range) |
| Protection Rating | IP44 (Dust & Splash-Resistant) |
| Termination Style | 3-Wire Leads (Flexible Connection) |
| Certifications | CE, CSA, UL (Global Compliance) |
| Weight | 70 oz (1.99 kg) |
W2E200 Series – Industrial Cooling Solutions
Series Highlights
✔ Ball Bearing Durability: Maintenance-free design for extended use.
✔ Shaded-Pole Motor: Energy-efficient & reliable performance.
✔ Aluminum & Steel Construction: High resistance to wear and corrosion.
✔ IP44 Protection: Prevents dust and moisture ingress.
Alternative Models in W2E200 Series
| Model | Key Differences | Best For |
|---|---|---|
| W2E200-HH82-01 | Flat Pin Terminals | Compact equipment cooling |
| W2E200-HH86-05 | Discharge Grill Included | Safety-focused applications |
| W2E200-HH86-90 | Tachometer Output (Speed Sensing) | Automated ventilation control |
| W2E200-HK38-01 | 230V, Higher CFM (650+) | Heavy-duty cooling |
Recommended Alternatives
- W3G250-HK35-11 – Higher CFM (1120) for large-scale cooling
- W2E200-HK38-01 – 230V version for high-power applications
Applications for W2E200-HH82-18
1️⃣ Industrial Machinery Cooling
CNC machines, welding systems, compressors.
2️⃣ HVAC & Ventilation Systems
Air handlers, ducted exhausts.
3️⃣ Server/Data Center Cooling
Rack-mounted applications with constrained space.
Why Choose the W2E200-HH82-18?
✅ Optimized Airflow Performance: 500 CFM with low noise (56 dB(A)).
✅ Rugged Construction: Ball bearings & aluminum housing for durability.
✅ Flexible Installation: 3-wire leads for easy integration.
Conclusion
The W2E200-HH82-18 is a premium 115V AC axial fan balancing performance, durability, and ease of use. Compare it with other W2E200 series models for varying airflow or voltage requirements.
