W1G300-BB23-01 ebm-papst W1G300-BB23-01 EC Axial Fan | 115V 823 CFM IP55 Energy-Saving Fan
The ebm-papst W1G300-BB23-01 is a high-efficiency 115V EC axial fan delivering 823 CFM airflow with IP55 protection and 54 dB(A) noise. Featuring plastic blades & frame, ball bearings, and thermal protection, it’s ideal for HVAC and refrigeration applications.
Key Features
⚡ Energy Efficiency: Uses 60% less energy than conventional motors, cutting operational costs.
🔇 Low Noise Operation: Optimized impeller design delivers 54 dB(A) quiet performance.
🛡 Durable Protection: IP55-rated for dust/water resistance and ball bearings for 50,000+ hour lifespan.
In Stock
Request a Quoteebm-papst W1G300-BB23-01 EC Axial Fan – High-Airflow, Energy-Saving Ventilation
The W1G300-BB23-01 is part of ebm-papst’s Energy-Saving Motor (ESM) series, designed for HVAC, refrigeration, and industrial cooling. Its polypropylene/nylon construction minimizes weight while maintaining durability, making it ideal for high-airflow, low-power applications.
Technical Specifications (A-Z Sorted Attributes)
| Attribute | Specification |
|---|---|
| Air Flow | 823 CFM (23.3 m³/min) |
| Approval Agencies | CSA, EAC, UL, VDE |
| Bearing Type | Ball Bearing (Maintenance-Free) |
| Brand | ebm-papst |
| Configuration | Obround |
| Current Rating | 0.5A |
| Depth | 92mm |
| Fan Type | Tubeaxial |
| Frame Material | Polypropylene (PP) |
| Height | 360mm |
| Ingress Protection | IP55 (Dust/Water-Resistant) |
| Manufacturer P/N | W1G300-BB23-01 |
| Material | Plastic |
| Max Operating Temp | 50°C |
| Min Operating Temp | -30°C |
| Noise Level | 54 dB(A) |
| Nominal Voltage | 115V AC |
| Power Rating | 35W |
| Rotation | Counter-Clockwise (CCW) |
| RPM | 1300 RPM |
| Series | W1G300 (Energy-Saving EC Fans) |
| Static Pressure | 0.141 in H₂O (35.1 Pa) |
| Termination | Wire Leads (3 Wires) |
| Type | Axial Fan |
| Voltage Range | 115V (±10%) |
| Weight | 1750g (3.86 lbs) |
| Width | 360mm |
W1G300 Series – Energy-Efficient EC Fan Solutions
Series Highlights
✔ 60% Less Energy Consumption: Optimized motor/impeller design cuts power usage significantly.
✔ Space-Saving: Compact depth (92mm) maximizes installation flexibility.
✔ Humidity-Resistant: Specially designed for refrigeration environments.
✔ Dual-Speed Capability: Optional speed control reduces energy use further.
Alternative Models in W1G300 Series
| Model | Key Differences | Best For |
|---|---|---|
| W3G250-HK19-11 | 230V, Tachometer Signal Output | Smart ventilation systems |
| W3G250-HH53-03 | 115V, 846 CFM, Higher RPM (2040) | High-airflow industrial cooling |
| W3G250-HH07-03 | 230V, Locked Rotor Sensor | Critical equipment protection |
Recommended Alternatives
- W3G250-HH53-03 – Higher CFM (846) for intensive cooling needs.
- W2E200-HK38-01 – AC motor option for legacy 230V systems.
Applications for W1G300-BB23-01
1️⃣ Commercial Refrigeration
Walk-in coolers, freezer units, condenser cooling.
2️⃣ HVAC Systems
Air handlers, rooftop ventilation, ducted exhaust.
3️⃣ Industrial Equipment
Packing machines, control cabinets, process cooling.
Why Choose the W1G300-BB23-01?
✅ Energy Savings: 35W power draw vs. 70W+ conventional fans.
✅ Reliable Performance: IP55 protection ensures operation in damp/dusty areas.
✅ Easy Integration: 3-wire leads simplify electrical connections.
Conclusion
The W1G300-BB23-01 combines energy efficiency (823 CFM at 35W) with rugged IP55 protection, making it ideal for refrigeration and HVAC. Compare it to W3G250 models for higher airflow or smart-control features.
