AC3200JHU ebm-papst AC3200JHU AC Tubeaxial Fan | IP65, 115/230V, 84.8 CFM, Ball Bearing, 55 dB(A)
The ebm-papst AC3200JHU is a 115/230V dual-voltage IP65-rated tubeaxial fan delivering 84.8 CFM airflow with 55 dB(A) noise. Features ball bearings, auto-restart, and 70,000-hour lifespan for industrial cooling & ventilation.
Key Features
🌀 High Airflow (84.8 CFM) – Efficient cooling for demanding applications
🔒 IP65 Protection – Dust-tight & water-resistant for harsh environments
⚡ Dual Voltage (115/230VAC) – Flexible power compatibility
In Stock
Request a Quoteebm-papst AC3200JHU Tubeaxial Fan – High-Performance Industrial Cooling
The ebm-papst AC3200JHU is a rugged 92×92×72mm square tubeaxial fan designed for industrial cooling, thermal management, and ventilation systems. With 84.8 CFM (2.37 m³/min) airflow and 1.044 in H₂O (260 Pa) static pressure, it efficiently moves air in confined spaces while maintaining a low-noise 55 dB(A) operation.
Its dual-voltage (115/230V AC) motor with ball bearings ensures longevity (70,000 hours @40°C), while the IP65 rating guarantees dust-tight and water-resistant performance, ideal for harsh industrial, HVAC, and electrical applications. Approved by CE, CSA, UL, VDE, and CCC, it meets global safety standards for reliability.
Technical Specifications
| Attribute | Specification |
|---|---|
| Air Flow | 84.8 CFM (2.37 m³/min) |
| Approval Agencies | CCC, CE, CSA, UL, VDE |
| Bearing Type | Ball Bearing |
| Brand | ebm-papst |
| Configuration | Square |
| Fan Type | Tubeaxial (AC) |
| Features | Auto Restart, Dual Voltage (115/230VAC) |
| Frame Material | Plastic |
| IP Rating | IP65 (Dust Tight, Water Resistant) |
| Lifetime @40°C | 70,000 Hours |
| Max Operating Temperature | +70°C (158°F) |
| Minimum Temperature | -20°C (-4°F) |
| Noise Level | 55 dB(A) |
| Power Rating | 12W |
| Series | AC3200J |
| Size (L×W×H) | 92×92×72mm (3.6×3.6×2.8 in) |
| Speed | 6800 RPM |
| Static Pressure | 1.044 in H₂O (260 Pa) |
| Termination | 2 Wire Leads |
| Voltage Rating | 115/230V AC |
| Weight | 0.717 lb (325.22 g) |
Applications
✅ Industrial Equipment Cooling – Control panels, motor cooling, enclosures
✅ HVAC & Ventilation – Air handling units, ducted systems
✅ Medical & Laboratory Devices – Precision airflow control
✅ Food Processing & Packaging – IP65-rated resistance to contaminants
Why Choose the AC3200JHU?
1. High Airflow with Low Noise (55 dB(A))
- Optimized blade design delivers 84.8 CFM while minimizing operational noise.
- Ideal for noise-sensitive environments requiring robust heat dissipation.
2. IP65 Protection for Harsh Conditions
- Fully sealed against dust & water jets, suitable for washdown environments (food processing, outdoor industrial use).
3. Dual Voltage & Auto-Restart Function
- Supports 115V or 230V operation for global compatibility.
- Auto-restart feature automatically resumes operation after power interruptions.
4. Ultra-Long Service Life (70,000 Hours)
- Ball bearings and thermally stable plastics ensure reliable operation even in demanding applications.
AC3200J Series Comparison
| Model | Voltage | Key Features |
|---|---|---|
| AC3200JH | 85-265V AC | EC motor, locked-rotor protection |
| AC3200JHU | 115/230V AC | IP65, auto-restart, dual voltage |
Conclusion
The ebm-papst AC3200JHU is a versatile, high-performance tubeaxial fan delivering industrial-grade cooling with IP65 durability and energy-efficient operation. Whether for HVAC, industrial machines, or medical equipment, its dual-voltage flexibility, auto-restart function, and 70,000-hour lifespan ensure reliable, long-term performance.
🔹 Need system-specific airflow tuning? Contact ebm-papst’s technical engineers for custom solutions!
