8550A ebm-papst 8550A Tubeaxial Fan – 28.3 CFM, 230VAC, Sintec Bearing, IP20
ebm-papst 8550A AC axial fan delivers 28.3 CFM airflow at 230VAC with Sintec bearing technology, metal construction, and ultra-quiet 36 dBA operation for reliable industrial cooling.
- Ultra-Long Lifespan: Sintec bearing ensures 52,500 hours of continuous operation at 40°C.
- Robust Metal Construction: Aluminum housing + metal blades withstand demanding industrial conditions.
- Certified Safety Compliance: Approved by CE, CSA, UL, and VDE for global use.
In Stock
Request a QuoteThe ebm-papst 8550A is a high-efficiency 80mm × 80mm × 38mm tubeaxial fan designed for industrial ventilation, electronics cooling, and HVAC applications. Operating at 230VAC, it delivers 28.3 CFM (0.792 m³/min) airflow while maintaining a remarkably low noise level of 36 dB(A) – making it ideal for environments where acoustic performance matters.
Built with durable metal blades and frame, this fan features Sintec bearing technology for reduced friction and extended operational life (52,500 hours @ 40°C). With approvals from CE, CSA, UL, and VDE, the 8550A meets stringent safety and performance standards worldwide.
8000A Series Overview
ebm-papst’s 8000A Series comprises compact 80mm square AC tubeaxial fans with diverse airflow and noise profiles. Key advantages include:
- Voltage Options: Primarily 230VAC models.
- Bearing Choices: Sintec (low-maintenance) alternatives available.
- Termination Styles: Quick-connect terminals simplify installation.
Full Series Model Comparison
| Model | Airflow | Power | Noise | RPM | Bearing | IP Rating |
|---|---|---|---|---|---|---|
| 8556A | 28.3 CFM | 12W | 37 dB(A) | 2800 | Sintec | IP20 |
| 8550A | 28.3 CFM | 12W | 36 dB(A) | 2700 | Sintec | IP20 (this model) |
| 8850A | 21.2 CFM | 12.5W | 31 dB(A) | – | – | IP20 |
| 8880A | 17.1 CFM | 9W | 26 dB(A) | 1750 | – | IP20 |
8550A Product Attributes
| Attribute | Specification |
|---|---|
| Air Flow | 28.3 CFM (0.792 m³/min) |
| Approval Agency | CE, CSA, UL, VDE |
| Bearing Type | Sintec |
| Fan Type | Tubeaxial |
| Lifetime @ Temp. | 52,500 hours @ 40°C |
| Material – Blade | Metal |
| Material – Frame | Aluminum |
| Noise | 36.0 dB(A) |
| Operating Temperature | -10°C to +70°C (14°F to 158°F) |
| Power (Watts) | 12.00W |
| RPM | 2700 |
| Size / Dimension | 80mm × 80mm × 38mm |
| Termination | 2 Terminals |
| Voltage – Rated | 230VAC |
Performance & Applications
- Industrial Machinery: Cooling for control cabinets, motors, and compressors.
- Electronics Enclosures: Heat dissipation in telecom and server racks.
- Ventilation Systems: Supplemental airflow in commercial HVAC units.
For lower-noise needs, consider the 8880A (26 dB(A)); higher-RPM alternatives include the 8556A (2800 RPM). The 8550A strikes an optimal balance between airflow, acoustics, and durability, backed by ebm-papst’s engineering rigor.
Note: Specifications subject to change; consult official documentation for critical applications.
