3800 ebm-papst 3800 AC Axial Fan – 31.8 CFM, 115VAC, 26 dB(A), Sintec Bearing, 62,500-Hour Lifespan
ebm-papst 3800 AC axial fan provides 31.8 CFM airflow at 115VAC with ultra-quiet 26 dB(A) operation, durable Sintec bearing, and 62,500-hour service life for industrial and commercial cooling.
Key Features:
✅ Superior Acoustics: Just 26 dB(A) noise level—one of the quietest in its class.
✅ Ultra-Durable Bearing: Sintec sleeve bearing system ensures a 62,500-hour lifespan at 40°C (25,000 hours at max temp).
✅ Robust Metal Construction: Die-cast aluminum housing and painted steel impeller for long-lasting performance in harsh environments.
In Stock
Request a Quoteebm-papst 3800 AC Axial Fan Overview
The ebm-papst 3800 is a 92mm × 92mm × 38mm tubeaxial fan designed for high-efficiency and low-noise ventilation and cooling. Operating at 115VAC, it delivers 31.8 CFM (0.890 m³/min) airflow while maintaining an ultra-quiet 26 dB(A) noise level—ideal for applications requiring silent operation such as medical equipment, office electronics, and HVAC systems.
ebm-papst 3800 Product Specification
| Attribute | Specification |
|---|---|
| Air Flow | 31.8 CFM (0.890 m³/min) |
| Approval Agency | CE, CSA, UL, VDE |
| Bearing Type | Sintec sleeve bearing |
| Fan Type | Tubeaxial |
| Lifetime @ Temp. | 62,500 hrs @ 40°C / 25,000 hrs @ max temp |
| Material – Blade | Painted steel |
| Material – Frame | Die-cast aluminum |
| Noise | 26.0 dB(A) |
| Operating Temp. | -10°C to +80°C (14°F to 176°F) |
| Power (Watts) | 8.00W |
| RPM | 1900 RPM |
| Size / Dimension | 92mm × 92mm × 38mm |
| Termination | 2 wire leads (AWG 18, tin-plated) |
| Voltage – Rated | 115VAC |
| Weight | 0.926 lb (420.03 g) |
3000 Series Overview
The 3000 Series from ebm-papst comprises high-quality 92mm × 92mm AC axial fans for various industrial and commercial cooling needs.
Full 3000 Series Model Comparison
| Model | Voltage | Airflow | Noise | Power | RPM | Bearing |
|---|---|---|---|---|---|---|
| 3500 | 115VAC | 43.0 CFM | 35 dB(A) | 8W | 2500 | Sintec |
| 3506 | 115VAC | 43.0 CFM | 36 dB(A) | 8W | 2500 | Ball |
| 3550 | 230VAC | 39.4 CFM | 32 dB(A) | 9W | 2300 | Sintec |
| 3556 | 230VAC | 39.4 CFM | 33 dB(A) | 9W | 2400 | Ball |
| 3600 | 115VAC | 52.4 CFM | 41 dB(A) | 11W | 3100 | Sintec |
| 3606 | 115VAC | 52.4 CFM | 42 dB(A) | 11W | 3200 | Ball |
| 3650 | 230VAC | 44.1 CFM | 36 dB(A) | 12W | 2650 | Sintec |
| 3656 | 230VAC | 44.1 CFM | 37 dB(A) | 12W | 2700 | Ball |
| 3660 | 115/230VAC | 46.0 CFM | 39 dB(A) | 12W | 2650 | Sintec |
| 3666 | 115/230VAC | 46.0 CFM | 37 dB(A) | 12W | 2700 | Ball |
| 3800 | 115VAC | 31.8 CFM | 26 dB(A) | 8W | 1900 | Sintec |
| 3806 | 115VAC | 35.3 CFM | 29 dB(A) | 8W | 2150 | Ball |
| 3850 | 230VAC | 28.8 CFM | 24 dB(A) | 9W | 1750 | Sintec |
| 3856 | 230VAC | 31.8 CFM | 26 dB(A) | 9W | 1950 | Ball |
Performance & Applications
Industrial & Commercial Use Cases
✔ Medical Ventilation – Silent cooling for MRI machines, diagnostic equipment.
✔ Office & Telecom – Low-noise cooling for servers, routers, conference systems.
✔ HVAC & Air Handling – Energy-efficient airflow in ducted ventilation systems.
For higher speed & airflow, consider the 3606 (52.4 CFM @ 3200 RPM). For higher durability, the 3800’s 62,500-hour lifespan makes it one of the longest-lasting 92mm AC fans available.
🔹 Note: Features clockwise rotation (viewed toward rotor) and includes a grounding lug (M4x8 TORX screw) for electrical safety. An identical yet more efficient alternative is the ACmaxx Series.
